Page #20 background imageLoading...
Page #20 background image
October 2015
Service Instructions
127072E Rev. C
16
Section 3: Actuator Reassembly
Actuator Reassembly
NOTE:
Refer to Section 2 step 2.3.3 for correct position indicator placement. Install position indi-
cator (1-220) over the exposed shaft of position indicator assembly (1-140).
3�2�42 Install stop screw nuts (1-190) onto stop screws (1-180).
3�2�43 Install O-ring (2-90) onto stop screws (1-180).
3�2�44 Install two stop screws (1-180) into two stop screw holes on the front of housing (1-10).
3�2�45 Adjust both stop screws (1-180) back to settings recorded earlier in Section 2 at
step 2.3.2.
3�2�46 Tighten both stop screw nuts (1-190) securely.
3�3 Hydraulic Power Module Reassembly
NOTE:
Review Section 3.1 General Reassembly before proceeding with hydraulic power module
reassembly.
In Section 3.3 where the step indicates to "lubricate, coat or apply uid", use hydraulic uid
for lubricating the part being installed.
3�3�1 Lubricate piston rod (3-40) with uid.
3�3�2 Install O-ring seal (4-70) into the seal groove in piston rod (3-40).
3�3�3 Install two split ring halves (3-50) into the inner most groove in piston rod (3-40)
and retain with one retainer ring (3-60).
3�3�4 Install piston (3-30) onto piston rod (3-40) and up against split rings install as
instructed in step 3.3.3.
3�3�5 Install two split ring halves (3-50) into the outer most groove in piston rod (3-40)
and retain with one retainer ring (3-60).
3�3�6 Apply uid to the bore of cylinder (3-70).
3�3�7 Coat one piston bearing (4-45) with uid and install into the piston external seal groove.
3�3�8 Install piston (3-30), with piston rod (3-40), into cylinder (3-70) and leave the inner
most piston seal groove outside of the cylinder.
3�3�9 Coat one piston seal (4-60) with uid and install into the piston external seal groove.
CAUTION: INSTALL PISTON SEAL CORRECTLY
Install the piston seal with energizer ring facing the outside edge of piston (3-30).
3�3�10 Push the piston through the cylinder (3-70) until the outboard piston seal groove
is exposed.
NOTE:
Moving the piston (3-30) through the bore of cylinder (3-70) may require mechanical assistance.
