a. Click Next to continue to the Local display setup, if View local display setup was
selected on the Startup page.
15. Configure the parameters for the local display.
a. Use the drop-down arrow in the Display Items list box and select or modify the
parameters that will be displayed; the Display items, the Display units and the
Scroll delay.
4.2.1 Display Items
The Local Display’s labels and descriptions are shown below:
Local display labels, descriptions and valid unitsTable 4-1:
Local display labels, descriptions and valid units
QFLOW — Uncorrected volume flow rate
• ACF – Actual Cubic Feet
• ACM – Actual Cubic Meters
• MACF – Thousand Actual Cubic Feet
• MACM –Thousand Actual Cubic Meters
TDYVL — Current day’s forward uncorrected volume
• +ACF – Actual Cubic Feet
• +ACM – Actual Cubic Meters
• +MACF – Thousand Actual Cubic Feet
• +MACM –Thousand Actual Cubic Meters
TDYVL — Current day’s reverse uncorrected volume
• -ACF – Actual Cubic Feet
• -ACM – Actual Cubic Meters
• -MACF – Thousand Actual Cubic Feet
• -MACM –Thousand Actual Cubic Meters
YSTVL — Previous day’s forward uncorrected volume
• +ACF – Actual Cubic Feet
• +ACM – Actual Cubic Meters
• +MACF – Thousand Actual Cubic Feet
• +MACM –Thousand Actual Cubic Meters
YSTVL — Previous day’s reverse uncorrected volume
• -ACF – Actual Cubic Feet
• -ACM – Actual Cubic Meters
• -MACF – Thousand Actual Cubic Feet
TOTVL — Forward uncorrected volume
• +ACF – Actual Cubic Feet
• +ACM – Actual Cubic Meters
• +MACF – Thousand Actual Cubic Feet
• +MACM –Thousand Actual Cubic Meters
TOTVL — Reverse uncorrected volume
Configuration
Installation manual 91
