4.4 Using a Field Communicator to configure the
meter
Prerequisites
• Emerson Field Communicator software, license, installation guide and user manual
available on the Emerson Asset Optimization Field Communicator website:
http://www.emerson.com/en-us/catalog/ams-475-field-communicator
• Daniel HART Device Description (HART DD) installed for the meter
• Network configured for a Field Communicator
• Daniel Field Device Specification Manual (P/N 3-9000-762) available on the Daniel
website.
• System wiring diagram drawing number DMC-005324 (see Section A.1)
• Power supply
Procedure
1. Remove electrical power to the meter. If installed, remove the endcap security
latches and seals and then, remove the endcap.
2. Refer to the Field Communicator Users Manual wiring diagrams and commissioning
instructions provided with your handheld device. Register the product to activate
the end user license.
3. Fully charge the Field Communicator battery prior to use.
Important
Do not change the battery in a hazardous area environment. The power supply is not
intrinsically safe.
Wire Analog Output 1 (AO1) as shown in Section A.1, drawing DMC-005324.
4. Use the leads provided with the Field Communicator to connect to your device.
5. Press and hold the Power button on the Field Communicator until the green light
blinks.
6. Use the touch screen on the Field Communicator, the keypad or use the stylus to
navigate through the device menus.
7. Refer to the Menu tree in Section D.1.1 of the Daniel HART Field Device Specification
manual (P/N 3-9000-762) for the device fast key sequences. Included in the menu
tree are:
• Diagram Page 1 - 3410 Series Root Menu; Overview, Configure>Manual Setup
• Diagram Page 2 - Configure|Manual Setup (continued) and Alerts Setup
• Diagram Page 3 - Service Tools|Alerts and Variables
• Diagram Page 4 - Service Tools|Variables (continued), Service Tools|Trends, and
Service Tools|Maintenance
Configuration
Installation manual 109
