Daniel models 3415, 3416 and 3417 meter specificationsTable 1-1:
Daniel 3415, 3416 and 3417 meter specifications
Meter type Number of paths
• 3415: 4-path chordal design combined with a single-
path bounce design
• 3416: 4-path chordal design combined with a two-path
bounce design
• 3417: 3417 Two sets of 4-path chordal designs
Ultrasonic type
• Transit-time based measurement
• Spool piece with integral mount transducers
Enclosure materials • ASTM B26GrA356.0T6 Aluminum
- 100% conversion coated and exterior coated with a
polyurethane enamel
• ASTM A351 GrCF8MStainless Steel
- Passivated
Optional Local Display with a glass endcap on transmitter
enclosure
Meter performance
Introduction
12 Gas Ultrasonic Flow Meter
