84 Configure the Local Display
Section 5: Calibrate and configure the meter 3410 Series Gas Ultrasonic Meters Operations Manual
January 2018 3-9000-777 Rev E
TOTVL — Forward uncorrected volume
• +ACF – Actual Cubic Feet
• +ACM – Actual Cubic Meters
• +MACF – Thousand Actual Cubic Feet
• +MACM –Thousand Actual Cubic Meters
TOTVL — Reverse uncorrected volume
• -ACF – Actual Cubic Feet
• -ACM – Actual Cubic Meters
• -MACF – Thousand Actual Cubic Feet
• -MACM –Thousand Actual Cubic Meters
QBASE — Corrected volume flow rate
• SCF – Standard Cubic Feet
• SCM – Standard Cubic Meters
• MSCF – Thousand Standard Cubic Feet
• MSCM – Thousand Standard Cubic Meters
TDYVL — Current days forward corrected volume
• +SCF – Standard Cubic Feet
• +SCM – Standard Cubic Meters
• +MSCF – Thousand Standard Cubic Feet
• +MSCM – Thousand Standard Cubic Meters
TDYVL — Current days reverse corrected volume
• -SCF – Standard Cubic Feet
• -SCM – Standard Cubic Meters
• -MSCF – Thousand Standard Cubic Feet
• -MSCM – Thousand Standard Cubic Meters
YSTVL — Previous days forward corrected volume
• +SCF – Standard Cubic Feet
• +SCM – Standard Cubic Meters
• +MSCF – Thousand Standard Cubic Feet
• +MSCM – Thousand Standard Cubic Meters
YSTVL — Previous days reverse corrected volume
• -SCF – Standard Cubic Feet
• -SCM – Standard Cubic Meters
• -MSCF – Thousand Standard Cubic Feet
• -MSCM – Thousand Standard Cubic Meters
TOTVL — Forward corrected volume
• +SCF – Standard Cubic Feet
• +SCM – Standard Cubic Meters
• +MSCF – Thousand Standard Cubic Feet
• +MSCM – Thousand Standard Cubic Meters
TOTVL — Reverse corrected volume
• -SCF – Standard Cubic Feet
• -SCM – Standard Cubic Meters
• -MSCF – Thousand Standard Cubic Feet
• -MSCM – Thousand Standard Cubic Meters
Table 5-16 Local display labels, descriptions and valid units
Local display labels, descriptions and valid units
