3410 Series Gas Ultrasonic Meters Operations Manual Section 5: Calibrate and configure the meter
3-9000-777 Rev E January 2018
Configure the Local Display 85
• Scroll delay - Time interval for the selected display items to be shown on the Local Display.
Use the spin buttons to increase or decrease the time interval.
VEL — Average flow velocity
• Ft/S – Feet per Second
• M/S – Meters per Second
SOS — Average sound velocity
• Ft/S – Feet per Second
• M/S – Meters per Second
TEMP — Flow-condition temperature
• DEGF – Degrees Fahrenheit
• DEGC – Degrees Celsius
PRESS — Flow-condition pressure
• PSI – Pound per square inch
• MPA – Megapascals
FRQ1A — Frequency channel 1A
• HZ – Hertz
FRQ1B — Frequency channel 1B
• HZ – Hertz
KFCT1 — Frequency 1 K-factor
• CF – Cubic Feet
• CM –Cubic Meters
• MCF – Thousand Cubic Feet
• MCM –Thousand Cubic Meters
FRQ2A — Frequency channel 2A
• HZ – Hertz
FRQ2B — Frequency channel 2B
• HZ – Hertz
KFCT2 — Frequency 2 K-factor
• CF – Cubic Feet
• CM –Cubic Meters
• MCF – Thousand Cubic Feet
• MCM –Thousand Cubic Meters
AO1 — Analog Output 1 current
• MA – Milliamperes
AO2 — Analog Output 2 current
• MA – Milliamperes
Table 5-16 Local display labels, descriptions and valid units
Local display labels, descriptions and valid units
