3 Meter repairs
Topics covered in this chapter:
• Precautions
• T-Slot transducer removal and installation
• Transducer holder removal and installation
• Transducer cable removal and installation
• Replace the meter electronics
• Acquisition Module replacement
3.1 Precautions
This section includes discussion of the maintenance of Daniel 3410 Series Ultrasonic
Meters.
For reference, you may download the Daniel MeterLink Quick Start Manual from:
http://www2.emersonprocess.com/en-US/brands/daniel/Flow/ultrasonics/Pages/
MeterLink.aspx
CAUTION!
SURFACE TEMPERATURE HAZARD
The meter body and piping may be extremely hot or cold.
Wear appropriate personal protective equipment when coming in contact with the meter.
Failure to comply may result in injury.
CAUTION!
TRANSPORTATION HAZARD
When moving the meter, do not insert the forks of a forklift into the bore.
Inserting the forks may cause the meter to become unstable, resulting in injury or damage to
the bore and sealing face.
CAUTION!
TRIPPING HAZARD
Clear all obstacles or obstructions from the work area when transporting, installing or
removing the meter.
Failure to clear the work area may cause injury to personnel.
