Emerson Dixell XRB User Manual

1592038420 XRB30-60-70-77CH EN v1.1 2021.09.15 XRB 19/38
Label
Description
LT
NT
Level
FnE
Force status change from normal mode to energy saving mode (valid if
ErA=Aut)
2
2
Pr2
StE
Period to switch from normal mode to energy saving (valid if ErA=bAS)
04:00
04:00
Pr2
EtS
Period to switch from energy saving mode to normal (valid if ErA=bAS)
08:00
08:00
Pr2
dS
Open door time to switch from EtS to StE (valid if ErA=bAS)
3
3
Pr2
nES
Number of motion detections before disabling energy saving (valid if
ixF=EMt)
15
15
Pr2
n1H
Number of activations for relay output oA1 (thousands of)
r.o.
r.o.
Pr1
n1L
Number of activations for relay output oA1 (units of)
r.o.
r.o.
Pr1
n2H
Number of activations for relay output oA2 (thousands of)
r.o.
r.o.
Pr1
n2L
Number of activations for relay output oA2 (units of)
r.o.
r.o.
Pr1
n3H
Number of activations for relay output oA3 (thousands of)
r.o.
r.o.
Pr1
n3L
Number of activations for relay output oA3 (units of)
r.o.
r.o.
Pr1
n4H
Number of activations for relay output oA4 (thousands of)
r.o.
r.o.
Pr1
n4L
Number of activations for relay output oA4 (units of)
r.o.
r.o.
Pr1
n7d
Number of daily activations of digital input 1
r.o.
r.o.
Pr1
n7H
Number of total activations of digital input 1 (thousands of)
r.o.
r.o.
Pr1
n7L
Number of total activations of digital input 1 (units of)
r.o.
r.o.
Pr1
n8d
Number of daily activations of digital input 2
r.o.
r.o.
Pr1
n8H
Number of total activations of digital input 2 (thousands of)
r.o.
r.o.
Pr1
n8L
Number of total activations of digital input 2 (units of)
r.o.
r.o.
Pr1
rSd
Daily counters reset
no
no
Pr2
rSC
Total counters reset
no
no
Pr2
Hur
Hours
0
0
Pr2
Min
Minutes
0
0
Pr2
dAY
Day of the week
0
0
Pr2
dYM
Day of the month
0
0
Pr2
Mon
Month
0
0
Pr2
YAr
Year
0
0
Pr2
Hd1
First day of weekend
Sat
Sat
Pr2
Hd2
2nd day of weekend
Sun
Sun
Pr2
iLE
Energy saving cycle starting time on working days
nu
nu
Pr2
dLE
Energy saving cycle duration on working days
nu
nu
Pr2
iSE
Energy saving cycle starting time on weekends
nu
nu
Pr2
dSE
Energy saving cycle duration on weekends
nu
nu
Pr2
dd1
Sunday defrost
no
no
Pr2
dd2
Monday defrost
no
no
Pr2
dd3
Tuesday defrost
no
no
Pr2
dd4
Wednesday defrost
no
no
Pr2
dd5
Thursday defrost
no
no
Pr2
dd6
Friday defrost
no
no
Pr2
dd7
Saturday defrost
no
no
Pr2
Ld1
1st defrost starting time
00:00
00:00
Pr2
Ld2
2nd defrost starting time
00:00
00:00
Pr2
Ld3
3rd defrost starting time
00:00
00:00
Pr2
Ld4
4th defrost starting time
00:00
00:00
Pr2
Ld5
5th defrost starting time
00:00
00:00
Pr2
