Emerson E2 User Manual

Appendix B: Pressure/Voltage and Temperature/Resistance Charts for Eclipse Transducers & Emerson Retail Solutions Temp
Sensors
• B-1
Appendix B: Pressure/Voltage and
Temperature/Resistance Charts for Eclipse
Transducers & Emerson Retail Solutions
Temp Sensors
Table B-1 - Temp Sensor Temperature/Resistance Chart
Emerson Retail Solutions Temperature Sensors
Resistance (ohms) Temperature (F)
336,450 -40
234,170 -30
165,210 -20
118,060 -10
85,399 0
62,493 10
46,235 20
34,565 30
26,100 40
19,899 50
15,311 60
11,883 70
9,299 80
7,334 90
Table B-2
- Eclipse Voltage to Pressure Chart
Eclipse Transducers
Voltage
(VDC)
Pressure (PSI)
100 lb.
xducer
200 lb.
xducer
500 lb.
xducer
0.5 0 0 0
0.7 5 10 25
0.9 10 20 50
1.1 15 30 75
1.3 20 40 100
1.5 25 50 125
1.7 30 60 150
1.9 35 70 175
2.1 40 80 200
2.3 45 90 225
2.5 50 100 250
2.7 55 110 275
2.9 60 120 300
3.1 65 130 325
3.3 70 140 350
3.5 75 150 375
3.7 80 160 400
3.9 85 170 425
4.1 90 180 450
4.3 95 190 475
4.5 100 200 500

Emerson E2 Specifications

General

Model	E2
Manufacturer	Emerson
Category	Controller
Power Supply	24 VAC/VDC
Communication Protocols	Ethernet
Output Type	Relay, Analog
Communication Protocol	Ethernet
Application	Refrigeration and HVAC system control
