Emerson E2 User Manual

E-2 • E2 RX/BX/CX I&O Manual 026-1614 Rev 4 5-JAN-2013
Kilowatts* 0 6,552.9 0.1 0 496 2
Energy
Watt-Hours* 0 131,058,000 2000 0 9,920,000 40000
Kilowatt-Hours* 0 131,058 2 0 9,920 40
Parts Per Million
Parts Per Million* 0 32,764.5 0.5 0 2,480 10
Percentage
Percentage* 0 200 0.00305208 0 124 0.5
Revolutions Per Minute
Revolutions Per Minute* 0 65,529 1 0 2,480 10
RPM Change Rate
Revolutions Per Minute Per Minute* 0 6,552.9 0.1 0 4,960 20
Time
Milliseconds* 0 65,529 1 0 248 1
Seconds* 0 65,529 1 0 248 1
Minutes* 0 65,529 1 0 248 1
Hours* 0 6,552.9 0.1 0 248 1
Days* 0 6,552.9 0.1 0 248 1
Months* 0 6,552.9 0.1 0 248 1
Years* 0 6,552.9 0.1 0 248 1
Time (seconds display)* 0 65,529 1 0 248 1
Time (minutes display)* 0 6,552.9 0.1 0 248 1
Time (hours display)* 0 6,552.9 0.1 0 248 1
Volume
Liters* 0 248,056 3.78544 0 9,387.894 37.8544
Gallons 0 65,529 1 0 2,480 10
Cubic Meters* 0 1,855.57 0.0283168 0 70.2258 0.283168
Cubit Feet 0 65,529 1 0 2,480 10
REU_CCF* 0 65,529 1 0 248 1
Volume Change Rate (liquid)
Liters Per Second* 0 65.529 0.001 0 7.82319 0.0315451
Gallons Per Minute 0 1,038.66 0.0158503 0 124 0.5
REU_CCFH* 0 655.29 0.01 0 25 0
Volume Change Rate (gas)
Cubit Meters Per Second* 0 30.9262 0.000471947 0 1.17043 0.00471948
Cubic Feet Per Minute 0 65,529 1 0 2,480 10
Distance
Meters* 0 65,529 1 0 248 1
Feet 0 214,990 3.28084 0 813.648 3.28084
Inches 0 65,529 1 0 248 1
Centimeters 0 65,529 1 0 248 1
Distance Change Rate (speed)
Meters Per Second* 0 332.89 0.005080 0 248 1
Feet Per Minute 0 65,529 1 0 48,818.9 196.850
Meters Per Minute 0 19,973 0.304800 0 14,880 60
Frequency
Hertz* 0 6,552.9 0.1 0 248 1
Weight
Pounds (lb) 0 1,444.6 0.2 0 546.7 2.2
Kilograms (kg) 0 655.3 0.1 0 248 1

Emerson E2 Specifications

General

Model	E2
Manufacturer	Emerson
Category	Controller
Power Supply	24 VAC/VDC
Communication Protocols	Ethernet
Output Type	Relay, Analog
Communication Protocol	Ethernet
Application	Refrigeration and HVAC system control
