I-6 • E2 RX/BX/CX I&O Manual 026-1614 Rev 4 5-JAN-2013
pulse type
setting units per pulse 9-9
Insertion Temperature Probe. See Sensors, Inser-
tion Probe.
Inside Temperature Sensor. See Sensors, Inside
Temperature.
Installation Guide
16AI 6-21
4AO 6-18
8IO 6-20
CC-100/CS-100 8-6
E2 4-4
ESR8 8-7
MultiFlex 16 6-16
MultiFlex Combo 6-17
MultiFlex ESR 6-22, 6-23, 6-24
TD3 8-8
Internal Modems (New Processor Board) 3-5,
4-3
IRLDS
specifying the number of 10-2, 10-15
Irrigation
zones and cycles
cycle control types 11-52
cycle control types
timed 11-52
volume 11-52
cycle scheduling 11-52
flow sensor related tests 11-53
leak 11-53
obstructed zone 11-53
number of zones 11-51
override failsafe 11-53
service modes 11-53
zone inhibit 11-52
alarm 11-52
freeze lockout 11-52
rain delay 11-52
timed 11-52
volume 11-52
zone override 11-52
zones and cycles 11-51
-J-
Jumpers
Echelon termination
E2 4-2
RS485 termination
E2 4-2
termination
settings on I/O boards 6-4
-K-
Keyboard 2-2
Keypad 12-7
KW Transducer 9-6
KW Transducer. See also Sensors, KW Trans-
ducer.
-L-
LED Status
Keyboard 2-3
Main Board (CPU) 2-3
PIB 2-2
LEDs Plug-In I/O Card 4-3
License Management 10-19
Licensing 1-7
Light Commercial Thermostat 6-9
Advisory and Alarm 6-9
Input 6-9
Light Level Sensor 3-10
Lighting
alternate control 11-33
multi-logic combiner 11-33
offset solar 11-34
control method select 11-32
functions 11-32
overview 11-31
separate control
min ON/OFF cell 11-34
proof cell 11-34
slave scheduling 11-34
standard control 11-32
light level interface 11-32
schedule interface cell 11-33
unoccupied mode 11-33
Line Up ESR 11-6
Line Up MultiFlex ESR 11-6
Liquid Level Sensors 3-11
Log View 12-16
Logged Inputs and Outputs 12-15
Logging
power monitoring 11-45
Logging Groups 11-16
