Emerson FB3000 User Manual

FB3000 - CSA Approval Information
CD9411N
Issued: November 3, 2023
CSA-2
FB3000 4 Channel HART I/O Logic
Module
510114-01-0
3HRT04
FB3000 4 Channel HART I/O Personality
Module
510115-01-0
3HTSG4
FB3000 8 Channel Output
(Analog/Digital) Logic Module
400253-01-0, 510142-01-0
3AODO8 (spare)
OUT08
(configured)
FB3000 8 Channel Output
(Analog/Digital) Personality Module
400254-01-0, 510143-01-0
3OTSG8 (spare)
OUT08
(configured)
FB3000 4-Port Serial Communications
Logic Module
510158-01-0,
3SERL4, COM04
(configured)
FB3000 4-Port Serial Communications
Personality Module
510155-01-0
3SRSG4,
COM04
(configured)
General Information:
Manufacturer:
Bristol Inc. d.b.a. Remote Automation Solutions
CSA Master Contract Number:
179806
SRAM Backup Battery in Power
Modules (for memory and real-time
clock)
3V coin lithium battery BT1
(Renata model CR2450HT)
(Maxell model CR2450HR)
(Panasonic model BR2450A)
(Murata model CR2450W)
Rated Capacity: 490 mAh
Operating Temperature: –40
o
C to +125
o
C
SRAM Backup Battery in CPU
Module (for memory and real-time
clock)
3V coin lithium battery BT1
(Renata model CR1632).
Rated Capacity: 125 mAh
Operating Temperature: –40
o
C to +85
o
C
Protective earthing (PE) conductor
(ground wire)
#14 AWG (2.1mm
2
)
Fuses
Littelfuse® 0453010.MR Surface Mount Nano
2
Fuse
10 Amps @ 125VDC
Equipment Ratings:
Mode of Operation:
Continuous
Pollution Degree:
2
