Emerson FB3000 User Manual

FB3000 - CSA Approval Information
CD9411N
Issued: November 3, 2023
CSA-3
Installation Category:
DC supplied
Altitude:
2000 m
Humidity:
95% to temperatures up to 31
o
c decreasing
linearly to 50% r.h. at 40
o
c; max 80 % r.h. non-
condensing
Electrical Supply Rating:
Input rating: 10.5-30Vdc
Controller Circuit: Max 5A at10.5 - 30V dc
Field Circuit: Max 5A at10.5 - 30V dc
Ambient Temperature Range:
(Tamb)
-40
o
C to +75
o
C
Temperature Code:
T4
Vibration:
1.0 g for 10 to 150 Hz for 30 minutes; 0.5 g for 150
to 2000 Hz for 30 minutes
Locations:
The Emerson FB3000 Remote Terminal Unit
(RTU) is listed by the Canadian Standards
Association (CSA) as suitable for use in Class I,
Division 2, Groups A, B, C and D hazardous
locations (when installed in a suitably-rated
enclosure), and in Class I, Zone 2, AEX/Ex ec IIC Gc
hazardous locations (when installed in an IP54
enclosure per requirements of standards CSA/UL
60079-0 and CSA/UL 60079-7).
If no suitably-rated enclosure is provided, may
only be used in non-hazardous indoor locations.
Representative Power Supplies:
24V power supply at 10A to 20A as approved to
standard UL 60950-1.
Typical: Phoenix Contact
Quint-PS/1AC/24DC/10 or
Quint-PS/1AC/24DC/20
Extended Backplane Supported Configurations:
Voltage (Control/Loop)
Max number of
12MIO/12MIO
Personality Modules
installed
Max number of
12MIO/12MIO Personality
Modules with loop power
enabled
30V
31
26
24V
≤
V < 30V
31
21
