38 Chapter 6 Micro-Processing Controller
Liebert.CRV+ Series Air Cooled Precision Air Conditioner User Manual
Figure 6-16 CP Driver Alarm Menu
Note
The CP Driver Alarms are serious fault alarms. So they cannot be set to OFF, but can only be set to ENA and
DISA.
EEV Alarm
Select EEV Alarm on the Alarm Set screen to enter the screen shown in Figure 6-17. Press the Up or Down button
to scroll through the menus.
Figure 6-17 EEV Alarm Menu
Note
The EEV Alarms are serious fault alarms. So they cannot be set to OFF, but can only be set to ENA and
DISA.
Alarm Process
Select Alarm Process on the Alarm Set screen to enter the screen shown in Figure 6-18. Press the Up or Down
button to scroll through the menus.
Figure 6-18 Alarm Process Menu
6.6.3 Temp&Hum Set
Select Temp&Hum Set on Main Menu screen to enter the screen shown in Figure 6-19.
The temperature & humidity settings will not be cleared upon system power-off.
To Next Page
