Communication System Manual
UPS System: HIPULSE E
(Modbus/Jbus Interface) Description of Protocol
(04/07)
Page 5-13
5.9 PROGRAMMING PARAMETERS
Address Meaning
SIZE (BYTES)
Range / Resolution Format UPS MSS
40080 Rated voltage 2 Rotating HEX note 1
Lower limit on 2 00:99 (V
in
%) HEX
40081
rated input voltage
Upper limit on 2 00:99 (V
in
%) HEX
40082
rated input voltage
Lower limit on 2 00:99 (V
in
%) HEX
40083
rated output voltage
Upper limit on 2 00:99 (V
in
%) HEX
40084
rated output voltage
40085 Rated frequency 2 Rotating HEX note 1
40086 Deviation 2 0:9 (Frq %) HEX
40087 Slew Rate 2 Rotating HEX nota 1e 3
---
40088 Number of battery cells 2 190 : 210 HEX note 3
---
40089 Rated capacity 2 0:9999 (Ah) HEX note 3
---
40090 End of cell discharge 2 150 : 170 1/10 V HEX note 2 e 3
---
Pre-alarm for end of 2 170 : 190 1/10 V HEX note 2 e 3
---
40091
cell discharge Res. 1/10 Volt
Maximum cell voltage 2 230 : 270 1/10 V HEX note 2 e 3
---
40092
Res. 1/10 Volt
40093 Duration of battery test 2 00 :99 min. HEX note 2 e 3
---
40094 Battery test threshold 2 170 : 190 1/10 V HEX note 2 e 3
---
40095 UPS power 2 Rotating HEX note 1
---
40096 Nr. UPS connected 2 1 : 6 HEX
---
5.9.1 Notes on ‘Request for Programming Parameters’
Note
Measurements with rotating values
Rated input and output voltage
0x0 = 208 Volts
0x1 = 220 Volts
0x2 = 230 Volts
0x3 = 380 Volts
0x4 = 400 Volts
0x5 = 415 Volts
0x6 = 440 Volts
0x7 = 460 Volts
0x8 = 480 Volts
Rated frequency
0x0 = 50 Hz.
0x1 = 60 Hz.
Slew Rate
0x0 = 0.1 Hz./Sec.
0x1 = 0.5 Hz./Sec.
0x2 = 1.0 Hz./Sec.
