Emerson Liebert HiPulse E Series User Manual

Communication System Manual UPS System: HIPULSE E
(Modbus/Jbus Interface) Description of Protocol
(04/07) Page 5-21
5.15 MAP OF JBUS/MODBUS RTU ADDRESSES:
Address Meaning Size Fc3 Fc4 Fc6 Fc16 Can. Prg. UPS MSS
40001 UPS\MSS power 2 X X X X X X
40002 Panel software release 4 X X X X
40004 Logic software release 4 X X X X X
40006 Configuration 2 X X X X X X
40007 UPS\MSS status 2 X X X X X
40008 Alarm status 2 X X X X
40020 UPS\MSS HOUR 2 X X X X X X X
40021 UPS\MSS MINUTES 2 X X X X X X X
40022 UPS\MSS SECONDS 2 X X X X X X X
40025 UPS\MSS DAY 2 X X X X X X X
40026 UPS\MSS MONTHS 2 X X X X X X X
40027 UPS\MSS YEAR 2 X X X X X X X
40030 Alarm 1- 16 2 X X X X
40031 Alarm 17- 32 2 X X X X
40032 Alarm 33- 48 2 X X X X
40033 Alarm 49- 64 2 X X X X
40034 Alarm 65- 80 2 X X X X
40035 Alarm 81- 88 2 X X X X
40040 Vout L1-L2 2 X X X X X
40041 Vout L2-L3 2 X X X X X
40042 Vout L3-L1 2 X X X X X
40043 Vout L1-N 2 X X X X X
40044 Vout L2-N 2 X X X X X
40045 Vout L3-N 2 X X X X X
40046 I out L1 2 X X X X X
40047 I out L2 2 X X X X X
40048 I out L3 2 X X X X X
40049 I out N 2 X X X X X
40050 Active Power L1 2 X X X X X
40051 Active Power L2 2 X X X X X
40052 Active Power L3 2 X X X X X
40053 Bypass Freq. 2 X X X X X
40054 Inverter Freq. 2 X X X X X
40055 Vin L1-L2 2 X X X X X
40056 Vin L2-L3 2 X X X X X
40057 Vin L3-L1 2 X X X X X
40058 Battery Voltage 2 X X X X
40059 Battery Current 2 X X X X
40060 Apparent Power L1 2 X X X X X
40061 Apparent Power L2 2 X X X X X
40062 Apparent Power L3 2 X X X X X
40063 Percent Load L1 2 X X X X X
40064 Percent Load L2 2 X X X X X
40065 Percent Load L3 2 X X X X X
40066 Batt. Charge Percentage 2 X X X X
40067 Batt. Time Remaining 2 X X X X
40068 Batt. Temperature 2 X X X X
