5.7 ALARM STATUS
Address Meaning Size (bytes)
Range /
Resolution
Format
40030 Alarm 1- 16 2 HEX note 1
40031 Alarm 17- 32 2 HEX note 2
40032 Alarm 33- 48 2 HEX note 3
40033 Alarm 49- 64 2 HEX note 4
40034 Alarm 65- 80 2 HEX note 5
40035 Alarm 81- 88 2 HEX note 6
5.7.1 Notes regarding ‘Request for Alarm Status’
Note  Alarms 0 through 15
Meaning UPS MSS
bit 0 Not in use
 
bit 1 NORMAL OPERATION
 
bit 2 BYPASS SWITCH OPEN
 
bit 3 OUTPUT SWITCH OPEN
 
bit 4 RECTIF. SWITCH OPEN

---
bit 5 BATTERY C.B. OPEN

---
bit 6 MANUAL BYPASS CLOSED
 
bit 7 ECHOMODE

---
bit 8 FAN FAILURE ALARM
 
bit 9 CRASH LOAD OPTION ---

bit 10 BYP: ABSENT
 
bit 11 BYP: OVERVOLTAGE
 
bit 12 BYP: UNDERVOLTAGE
 
bit 13 BYP: FREQUENCY ERROR
 
bit 14 BYP: PHASE ROT.ERROR
 
bit 15 BYP: SCR FAILURE
 
Note  Alarms 16 through 31
Meaning UPS MSS
bit 0 BYPASS: OFF
 
bit 1 BYP: OFF VIA REMOTE
 
bit 2 LOAD ON BYPASS
 
bit 3 BYP: OVERTEMPERATURE

---
bit 4 RECTIFIER: OFF

---
bit 5 RECT: OFF VIA DISPL.

---
bit 6 RECTIFIER: BLOCK

---
bit 7 RECT: CURRENT LIMIT

---
bit 8 RECT: OVERTEMPERAT.

---
bit 9 RECT: FUSE FAIL

---
bit 10 BATTERY FAST CHARGE ON *NOTE

---
bit 11 CAPACITY OVERLOAD PROTECTION *NOTE

---
bit 12 POWER WALKIN ON

---
bit 13 LOAD ON INVERTER *NOTE

---
bit 14 INVERTER: OFF

---
bit 15 INV: OFF VIA DISPLAY
 
