UPS System: HIPULSE E
Communication System Manual
Description of Protocol (Modbus/Jbus Interface)
Page 5-8
(04/07)
Note
Alarms 32 through 47
Meaning UPS MSS
bit 0 INVERTER: BLOCK
---
bit 1 INV: CURRENT LIMIT
---
bit 2 INV: OVERTEMPERATURE
bit 3 INV: UNSYNCHRONIZED
bit 4 INV: OVERVOLTAGE
---
bit 5 INV: UNDERVOLTAGE
---
bit 6 INV: FUSE FAIL
---
bit 7 OUTPUT: OVERVOLTAGE
bit 8 OUTPUT: UNDERVOLTAGE
bit 9 OUTPUT: NO VOLTAGE
bit 10 OUTPUT: WAVEFORM ERR
bit 11 INV: FREQUENCY ERROR
bit 12 INV: PARALLEL ERROR
---
bit 13 CONTACTOR FAILURE
---
bit 14 NR.INVERTERS NOT OK
bit 15 PARALLEL BUS OPEN ---
Note
Alarms 48 through 63
Meaning UPS MSS
bit 0 x UPS NOT ACTIVE ---
bit 1 x UPS REDONDANCE ---
bit 2 BATTERY: UNDER TEST
---
bit 3 BATTERY: TEST FAILED
---
bit 4 BATTERY: ON LOAD
---
bit 5 BATTERY: END DISCH.
---
bit 6 BOOST: TIME EXPIRED
---
bit 7 DC BUS: SLOW OVERVOL
---
bit 8 DC BUS: UNDERVOLTAGE
---
Bit 9 BATTERY: FUSE FAIL
---
Bit 10 DC BUS: FAST OVERVOL
---
Bit 11 BATTERY GROUND FAULT
---
Bit 12 BYP:XFER COUNT BLOCK
Bit 13 OVERLOAD SHUTDOWN
---
Bit 14 OVERTEMPER.SHUTDOWN
---
Bit 15 EMERGENCY STOP
