Communication System Manual
UPS System: HIPULSE E
(Modbus/Jbus Interface) Description of Protocol
(04/07)
Page 5-9
Note
Alarms 64 through 79
Meaning UPS MSS
Bit 0 BACKFEED FAULT
Bit 1 SYNCHRO. INHIBITED ---
Bit 2 OVERLOAD PRESENT
Bit 3 OVERLOAD SHUTDOWN
---
Bit 4 RES/IND OVERLOAD PROTECTION *NOTE
---
Bit 5 PEAK CURRENT PROTECTION
---
Bit 6 BAD EEPROM PROGRAMM.
Bit 7 ERROR LRC PAR. PAG 1
bit 8 ERROR LRC PAR. PAG 2
bit 9 ERROR LRC PAR. PAG 3
bit 10 ERROR LRC ALARM HIS.
bit 11 ERROR LRC EVENT HIS.
bit 12 INTERNAL BATTERY LOW
bit 13 ERR. LRC RAM UPTIME
bit 14 WATCH-DOG RESET
bit 15 ERR. LRC RAM BATT.
---
Note
Alarms 80 through 88
Meaning UPS MSS
bit 0 LRC error in reset table
bit 1 LRC error in panel parameters
bit 2 Not used ---
bit 3 LRC error in panel alarms
bit 4 Not used ---
bit 5 Not used ---
bit 6 JBUS TIMEOUT TRASM.
bit 7 CAN BUS NO RESPONSE
bit 8 AUTONOMY XXXX min
---
bit 9-10-11- Not in use
bit 12-13-14-15 Not in use
*NOTE :FROM FIRMWARE REL 19.1
