Communication System Manual
UPS System: HIPULSE E
(Modbus/Jbus Interface) Description of Protocol
(04/07)
Page 5-15
5.10 EVENT HISTORY IN SELECTED BUFFER
This command may be used to read messages stored in the <Event-History> records.
Position Meaning Size (bytes)
Values Format UPS MSS
40150 ALARM HOUR 2 0 : 23 ASCII
40151 ALARM MINUTES 2 0 : 59 ASCII
40152 ALARM SECONDS 2 0 : 59 ASCII
40153 ALARM DAY 2 1 : 31 ASCII
40154 ALARM MONTH 2 1 : 12 ASCII
40155 ALARM YEAR 2 00: 99 ASCII
40156 UPS status (ALARM) 2 HEX note 1
40157 Alarm status 2 Rotating HEX note 2
40158 Alarm code 2 0 : 79 HEX
40159 Alarm 1- 16 (Alarm Hist) 2 - HEX note 3
40160 Alarm 17- 32(Alarm Hist) 2 - HEX note 3
40161 Alarm 33- 48(Alarm Hist) 2 - HEX note 3
40162 Alarm 49- 64(Alarm Hist) 2 - HEX note 3
40163 Alarm 65- 80(Alarm Hist) 2 - HEX note 3
40164 Vout L1-L2(Alarm Hist) 2 1 Volt HEX
40165 Vout L2-L3(Alarm Hist) 2 1 Volt HEX
40166 Vout L3-L1(Alarm Hist) 2 1 Volt HEX
40167 Vout L1-N(Alarm Hist) 2 1 Volt HEX
40168 Vout L2-N(Alarm Hist) 2 1 Volt HEX
40169 Vout L3-N(Alarm Hist) 2 1 Volt HEX
40170 I out L1(Alarm Hist) 2 1 Ampere HEX
40171 I out L2(Alarm Hist) 2 1 Ampere HEX
40172 I out L3(Alarm Hist) 2 1 Ampere HEX
40173 I out N(Alarm Hist) 2 1 Ampere HEX
40174 Active Power L1(Alarm Hist) 2 1 kWatt HEX note 4
40175 Active Power L2(Alarm Hist) 2 1 kWatt HEX note 4
40176 Active Power L3(Alarm Hist) 2 1 kWatt HEX note 4
40177 Bypass Freq. (Alarm Hist) 2 0.1 Hz HEX note 4
40178 Inv. Freq. (Alarm Hist) 2 0.1 Hz HEX note 4
40179 Vin L1-L2(Alarm Hist) 2 1 Volt HEX
40180 Vin L2-L3(Alarm Hist) 2 1 Volt HEX
40181 Vin L3-L1(Alarm Hist) 2 1 Volt HEX
40182 V batt(Alarm Hist) 2 1 Volt HEX note 5
---
40183 I batt(Alarm Hist) 2 1 Ampere HEX note 4 e 5
---
40184 Apparent Power L1(Alarm Hist) 2 1 KVA HEX
40185 Apparent Power L2(Alarm Hist) 2 1 KVA HEX
40186 Apparent Power L3(Alarm Hist) 2 1 KVA HEX
40187 Percent Load L1(Alarm Hist) 2 000:100 % HEX
40188 Percent Load L2(Alarm Hist) 2 000:100 % HEX
40189 Percent Load L3(Alarm Hist) 2 000:100 % HEX
40190 Batt. Charge (Alarm Hist) 2 000:100 % HEX note 4 e 5
---
40191 Batt.Time Remain (Alarm Hist) 2 Min. HEX note 4 e 5
---
40192 Batt. Temp.(Alarm Hist) 2 0.1 °C HEX note 4 e 5
---
5.10.1 Notes on ‘Selected Buffer Event History Request’
Note
UPS status:
bit 0 UPS Inverter status 0 = Inverter OFF 1 = Inverter ON
bit 1 UPS mains status 0 = Mains OFF 1 = Mains ON
bit 2 UPS rectifier status 0 = Rectifier OFF 1 = Rectifier ON
bit 3 UPS rectifier status 0 = Rectifier on buffer 1 = Rectifier manual
bit 4 UPS battery charge status 0 = Battery on load 1 = Battery charging
bit 5 UPS battery test status 0 = Battery test inactive 1 = Battery test in progress
bits 6 through 15 not in use
