Figure 10-16 D3 or D3 and D4 density calibration – Communicator
10.6 Performing temperature calibration
Temperature calibration is a two-part procedure: temperature offset calibration and temperature slope
calibration. The entire procedure must be completed without interruption.
You can calibrate for temperature with ProLink II. See Figure 10-17.
Enter density of D3 fluid
Density Calibration
Complete message
Calibration in Progress
message
D3 calibration
Close shutoff valve
downstream from sensor
Fill sensor with D3 fluid Fill sensor with D4 fluid
D4 calibration
OK
3 Dens Pt 3
Perform Cal
OK
Home
Enter density of D4 fluid
Density Calibration
Complete message
Calibration in Progress
message
OK
4 Dens Pt 4
Perform Cal
OK
Home
Done
On-Line Menu >
3 Diag/Service >
3 Calibration >
2 Density cal
3 Diag/Service >
3 Calibration >
2 Density cal
Done
