F.4 Communicator menus
Figure F-5 Communicator process variables menu
On-Line Menu >
1 Process variables
View fld dev vars
1 Mass flo
2 Temp
3 Mass totl
4 Dens
5 Mass inventory
6 Vol flo
7 Vol totl
8 Vol inventory
9 Pressure
View API vars
View ED vars
View output vars
1 View PV-Analog 1
2 View SV-Analog 2
3 View TV-Freq/DO
4 View QV
(1)
5 View event 1
6 View event 2
View status Totlizer contrl
1 Mass totl
2 Vol totl
3 Start totalizer
4 Stop totalizer
5 Reset all totals
6 Reset mass total
7 Reset volume total
8 Reset API ref
9 Reset ED ref
Reset ED net ma
Reset ED net vol
Reset gas std. vol
