186 Micro Motion Series 1000 and Series 2000 Transmitters
Menu Flowcharts – Model 1500 AN Transmitters
Figure C-6 Communicator diagnostics/service menu
On-Line Menu >
2 Diag/Service
Test/Status
1 View status
2 Self test
Loop test
1 Fix analog out 1
2 Fix frequency out
Calibration
1 Auto zero
2 Density cal
3 Meter verification
Perform diagnostic action
1 Reset alarm log
2 Acknowledge all alarms
3 Reset Power On time
4 Restore factory configuration
5 Reset all ED curve information
6 Enable write protect
7 Disable write protect
8 Restore factory zero
9 Exit
21
Config alarms
1 Write severity
2 Read severity
3 Review severity
4 Acknowledge selected alarm
5 Alarm history
6 Refresh alarm history
Trim analog out 1
Scaled AO1 trim
Test points
1 Status words
2 LPO
3 RPO
4 Tube
5 Drive
6 Board temperature
7 Meter temp. T-Series
8 Live zero flow
9 Meter temp. T-Series
Input voltage
Actual target amplitude
Average sensor temp
Min sensor temp
Max sensor temp
Average electronics temp
Min electronics temp
Wire RTD
Meter RTD
Line RTD
Power cycle count
Power on time
Max electronics temperature
Drive current
3
6 7
4
Read outputs
5 8
