Menu Flowcharts – Model 2500 CIO Transmitters
Diagrams Model 2500 CIOModel 1500 ANDefaults Diagrams Model 2500 CIOModel 1500 ANDefaults Diagrams Model 2500 CIOModel 1500 ANDefaults Diagrams Model 2500 CIOModel 1500 ANDefaults
Figure D-9 Communicator detailed setup menu continued
On-Line Menu >
5 Detailed Setup
3
Config outputs
1 Channel setup
2 HART output
3 RS485 setup
4 Fault timeout
5 Comm fault indicator
1 Channel setup (read only)
2 Channel A setup
3 Channel B setup
4 Channel C setup
5 AO setup
6 FO setup
7 DI/DO setup
1
6
Additional options
3
1 Channel A (read-only)
2 Channel B (read-only)
3 PV is
4 Range values
5 PV AO cutoff
6 PV AO added damp
7 AO1 fault setup
8 SV is
9 Range values
SV AO2 cutoff
SV AO added damp
AO2 fault setup
1 Channel B (read-only)
2 Channel C (read-only)
3 TV is
4 FO scale method
5 TV freq factor
6 TV rate factor
5 TV pulses/unit
5 TV units/pulse
6/7 Max pulse width
7/8 Polarity
8/9 FO fault indicator
9/ FO fault value
1 Output option board
2 RS485 protocol
3 RS485 baudrate
4 RS485 parity
5 RS485 stop bits
6 Modbus address
7 Comm fault indicator
1 Poll addr
2 Num preambles
3 Burst mode
4 Burst option
5 Burst var 1
6 Burst var 2
7 Burst var 3
8 Burst var 4
2
3
1 External
2 Internal
2, 3
1 Milliamp output
2
4
1 Milliamp
2 Frequency output
3 Discrete output
1 Frequency output
2 Discrete output
3 Discrete input
1 External
2 Internal
5
1 Channel B (read-only)
2 Channel C (read-only)
3 DO1 is
4 DO1 polarity
5 DO1 fault indicator
6 DO2 is
7 DO2 polarity
8 DO2 fault indicator
9 Flow switch setpoint
Flow switch variable
7
