244 Micro Motion Series 1000 and Series 2000 Transmitters
Menu Flowcharts – Model 2700 CIO Transmitters
Figure G-8 Communicator detailed setup menu
On-Line Menu >
5 Detailed Setup
21
Charize sensor
1 Sensor selection
2 Flow
3 Density
4 Temp cal factor
5 Pressure compensation
6 Meter factors
7 Update rate
8 Update rate var
8/9 Polling setup
9/ External temp
1 D1
2 K1
3 D2
4 K2
5 Temp coeff
(1)
5 DTG
(2)
6 FD
(1)
6 DFQ1
(2)
7 DFQ2
(2)
8 DT
(2)
9 FD
(2)
D3
(2)
K3
(2)
D4
(2)
K4
(2)
1 FlowCal
(1)
1 FCF
(2)
2 FTG
(2)
3 FFQ
(2)
1 T-Series
2 Other
1 Enable pressure
2 Flow factor
3 Dens factor
4 Flowcal pressure
5 Static pressure
1 Mass factor
2 Vol factor
3 Dens factor
1 Poll control 1
2 External device tag 1
3 Polled var 1
4 Poll control 2
5 External device tag 2
6 Polled var 2
1 Enable ext temp
2 Static temperature
1
3
2
5
6
9/
Config fld dev vars
1 Flow
2 Density
3 Temperature
4 Pressure
5 API
1 Mass flow unit
2 Mass flow cutoff
3 Spcl mass units
4 Vol flow unit
5 Vol flow cutoff
6 Spcl vol units
7 Flo direction
8 Flo damp
1
1 Density unit
2 Density damp
3 Density cutoff
4 Slug low limit
5 Slug high limit
6 Slug duration
1 Temp unit
2 Temp damp
1 Pressure unit
2
3
4
Additional options
Normal
Special
7
1 API setup
2 Enable API
3 API 2540 CTL table
4 API Thermal Exp
5 API Reference Temp
5
(1) Displayed only if Sensor Selection is set to Other.
(2) Displayed only if Sensor Selection is set to T-Series.
