Alert num-
ber Alert title Possible cause Recommended actions
A009 Transmitter Initializ-
ing/Warming Up or
Significant Process
Instability
Transmitter is in power-up mode.
If this occurs after device startup,
measurement stability has dropped
below acceptable limits and the de-
vice is repeating its startup se-
quence.
Allow the meter to complete its power-
up sequence. The alert should clear au-
tomatically.
If other alerts are present, resolve those
alert conditions first. If the current alert
persists, continue with the recommen-
ded actions.
Verify that the transmitter is receiving
sufficient power.
- If it is not, correct the problem and
cycle power to the meter.
- If it is, this suggests that the trans-
mitter has an internal power issue.
Replace the transmitter.
Ensure that the process fluid is stable.
Check for two-phase flow, high process
noise, or a fast transition between two
fluids of different densities.
A010 Calibration Failure Many possible causes.
This alert will not clear until you cy-
cle power to the meter.
Ensure that your calibration procedure
meets the documented requirements,
cycle power to the meter, then retry the
procedure.
A014 Transmitter Failure Many possible causes. Ensure that all wiring compartment
covers are installed correctly.
Ensure that all transmitter wiring meets
specifications and that all cable shields
are properly terminated.
Check the grounding of all compo-
nents. See Section 10.3.
Evaluate the environment for sources of
high electromagnetic interference
(EMI) and relocate the transmitter or
wiring as necessary.
Contact Micro Motion.
A016 Sensor Temperature
(RTD) Failure
The value computed for the resist-
ance of the line RTD is outside lim-
its.
Check your process conditions against
the values reported by the device.
Contact Micro Motion.
A020 Calibration Factors
Missing
Some calibration factors have not
been entered or are incorrect.
Verify all of the characterization or cali-
bration parameters. See the sensor tag
or the calibration sheet for your meter.
A021 Transmitter/Sensor/
Software Mismatch
The configured board type does not
match the physical board.
Verify all of the characterization or cali-
bration parameters. See the sensor tag
or the calibration sheet for your meter.
Ensure that the correct board is instal-
led.
Troubleshooting
142 Micro Motion
®
Fork Density Meters (FDM)
