- If the current value is positive and there is a blank space at the left of the value,
activate Select until the cursor is flashing under the blank space, then activate
Scroll until the minus sign appears.
- If the current value is positive and there is no blank space at the left of the value,
activate Select until the cursor is flashing under the leftmost digit, then activate
Scroll until the minus sign appears.
• To move the decimal point:
1. Activate Select until the decimal point is flashing.
2. Activate Scroll.
The decimal point is removed from its current position.
3. Activate Select and watch the position of the decimal point.
As the cursor moves to the left, the decimal point will flash between each pair of
digits, up to a maximum precision of four (four digits to the right of the decimal
point).
Tip
If the position is not valid, the decimal point is not displayed. Continue to activate Select
until the decimal point appears at the right of the displayed value.
4. When the decimal point is in the desired position, activate Scroll.
The decimal point is inserted at its current position.
• To save the displayed value to transmitter memory, activate Scroll and Select
simultaneously and hold until the display changes.
- If the displayed value is the same as the value in transmitter memory, you will be
returned to the previous screen.
- If the displayed value is not the same as the value in transmitter memory, SAVE/
YES? flashes on the display. Activate Select.
• To exit the menu without saving the displayed value to transmitter memory,
activate Scroll and Select simultaneously and hold until the display changes.
- If the displayed value is the same as the value in transmitter memory, you will be
returned to the previous screen.
- If the displayed value is not the same as the value in transmitter memory, SAVE/
YES? flashes on the display. Activate Scroll.
Enter a floating-point value using exponential notation
Exponential notation is used to enter values that are larger than 99999999 or smaller than
−9999999.
Exponential values entered via the display must be in the following form: SX.XXXEYY. In
this string:
Using the transmitter display
166 Micro Motion
®
