12.3 Optional external EMC filters
EMC filters can be sourced directly from Schaffner and Epcos. See Table 12-45 for details.
Table 12-45 Mentor MP and EMC filter cross reference
* This filter is required if the input current to the Mentor MP will be greater than 66Amps.
It is essential that line reactors be connected between the
filter terminals and the power input terminals, as shown in
Figure 4-1. Failure to observe this requirement could result in
destruction of the thyristors.
Model
Manufacturers part number
Schaffner armature
standard
Schaffner armature
high performance
Epcos
armature
high performance
Schaffner standard
field filter
Epcos standard
field filter
MP25A4(R)
FN3270H-80-35 FN3258-75-52
B84143-A66-R105
FN3280H-8-29 W62400-T1262D004
MP45A4(R)
MP75A4(R) *B84143-A90-R105
MP105A4(R)
FN3270H-200-99 FN3258H-180-40 B84143BO250S080MP155A4(R)
MP210A4(R)
MP350A4 (R)
FN3359-800-99
FN3280H-25-33
MP420A4 (R)
MP550A4 (R)
MP700A4 (R)
MP825A4(R)
MP900A4 (R)
MP1200A4 (R)
FN3359-1600-99
MP1850A4 (R)
CAUTION
