90 Mentor MP User Guide
www.controltechniques.com Issue: 3
Table 11-3 Feature look-up table
Feature Related parameters (Pr)
Acceleration rates 2.10 2.11 to 2.19 2.32 2.33 2.34 2.02
Analog speed reference 1 1.36 7.10 7.01 7.07 7.08 7.09 7.25 7.26 7.30
Analog speed reference 2 1.37 7.14 1.41 7.02 7.11 7.12 7.13 7.28 7.31
Analog I/O
Menu
7
Analog input 1 7.01 7.07 7.08 7.09 7.10 7.25 7.26 7.30
Analog input 2 7.02 7.11 7.12 7.13 7.14 7.28 7.31
Analog input 3 7.03 7.15 7.16 7.17 7.18 7.29 7.32
Analog output 1 7.19 7.20 7.21 7.33
Analog output 2 7.22 7.23 7.24
Application menu Menu 18 Menu 19 Menu 20
At speed indicator bit 3.06 3.07 3.09 10.06 10.05 10.07
Auto reset 10.34 10.35 10.36 10.01
Autotune 4.13 4.14 4.34 5.12 5.15 5.23 5.24 5.29 5.30 5.59 5.61 5.70 5.72 5.74
Binary sum 9.29 9.30 9.31 9.32 9.33 9.34
Bipolar speed 1.10
Brake control 12.40 to 12.49
Catch a spinning motor 6.09
Coast to stop 6.01
Comms 11.23 to 11.26
Copying 11.42 11.36 to 11.40
Cost - per kWh electricity 6.16 6.17 6.24 6.25 6.26 6.40
Current controller 4.13 4.14 4.34 5.15
Current feedback 4.01 4.02 4.16 4.19 4.20 4.27 4.28 4.29 4.30 4.31 4.32 10.08 10.17
Current limits 4.05 4.06 4.07 4.18 5.07 10.09
Deceleration rates 2.20 2.21 to 2.29 2.04 2.35 to 2.37 2.02 2.08 6.01
Defaults 11.46
Digital I/O
Menu
8
Digital I/O read word 8.20
Digital I/O T24 8.01 8.11 8.21 8.31
Digital I/O T25 8.02 8.12 8.22 8.32
Digital I/O T26 8.03 8.13 8.23 8.33
Digital input T27 8.04 8.14 8.24
Digital input T28 8.05 8.15 8.25 8.39
Digital input T29 8.06 8.16 8.26 8.39
Digital lock 13.10 13.01 to 13.09 13.11 13.12 13.16 3.22 3.23 13.19 to 13.23
Direction 10.13 6.30 6.31 3.01 3.02 10.14 8.03 8.04
Display timeout 11.41
Drive active 10.02
Drive OK 10.01 8.27 8.07 8.17 10.36
Electronic nameplate 3.49
Enable 6.15 8.09 8.10
Encoder reference 3.43 3.44 3.45 3.46
Encoder set up 3.33 3.34 to 3.42 3.47 3.48
External trip 10.32 8.10 8.07
Fan speed 6.45
Filter change 6.19 6.18
Hard speed reference 3.22 3.23
I/O sequencer 6.04 6.30 6.31 6.32 6.33 6.34 6.42 6.43 6.40
Inertia compensation 2.38 5.12 4.22 3.18
Jog reference 1.05 2.19 2.29
Keypad reference 1.17 1.14 1.43 1.51 6.12 6.13
Limit switches 6.35 6.36
Line power supply loss 6.03 5.05
Local position reference 13.20 to 13.23
Logic function 1 9.01 9.04 9.05 9.06 9.07 9.08 9.09 9.10
Logic function 2 9.02 9.14 9.15 9.16 9.17 9.18 9.19 9.20
Marker pulse 3.32 3.31
Maximum speed 1.06
Menu 0 set up 22.01 to 22.21 Menu 22
Minimum speed 1.07 10.04
Modules - number of 11.35
