Mentor MP User Guide 91
Issue: 3 www.controltechniques.com
Motor map 5.07 5.08 5.09 5.70 5.73
Motor map 2 Menu 21 11.45
Motorized potentiometer 9.21 9.22 9.23 9.24 9.25 9.26 9.27 9.28
Offset speed reference 1.04 1.38 1.09
Onboard PLC 11.47 to 11.51
Open collector digital outputs 8.30
Orientation 13.10 13.13 to 13.15
Output 5.01 5.02 5.03
Overspeed threshold 3.08
PID controller Menu 14
Position feedback - drive 3.28 3.29 3.30 3.50
Positive logic 8.29
Power up parameter 11.22 11.21
Precision reference 1.18 1.19 1.20 1.44
Preset speeds 1.15 1.21 to 1.28 1.16 1.14 1.42 1.45 to 1.48 1.50
Programmable logic
Menu
9
Regenerating 10.10
Relative jog 13.17 to 13.19
Relay output 8.07 8.17 8.27 8.40 8.50 8.60
Reset 10.33 8.02 8.22 10.34 10.35 10.36 10.01
S ramp 2.06 2.07
Security code 11.30 11.44
Serial comms 11.23 to 11.26
Skip speeds 1.29 1.30 1.31 1.32 1.33 1.34 1.35
SMARTCARD 11.36 to 11.40 11.42
Software version 11.29 11.34
Speed controller 3.10 to 3.17 3.20 3.21
Speed feedback 3.02 3.03
Speed feedback - drive 3.26 3.27 3.28 3.29 3.31 3.42 3.52 3.55 3.56 3.57 3.58
Speed reference selection 1.14 1.15 1.49 1.50 1.01
Status word 10.40
Supply 5.05
Thermal protection - drive 7.04 7.34 10.18
Thermal protection - motor 4.15 5.07 4.19 4.16 4.25 7.15
Thermistor input 7.15 7.03
Threshold detector 1 12.01 12.03 to 12.07
Threshold detector 2 12.02 12.23 to 12.27
Time - filter change 6.19 6.18
Time - powered up log 6.20 6.21 6.28
Time - run log 6.22 6.23 6.28
Torque 4.03 4.26 5.32
Torque mode 4.08 4.11 4.09 4.10
Trip detection 10.20 to 10.29
Trip log 10.20 to 10.29 10.41 to 10.51 6.28
Under voltage 5.05
Variable selector 1 12.08 to 12.15
Variable selector 2 12.28 to 12.35
Velocity feed forward 1.39 1.40
Voltage rating 11.33 5.09 5.05
Warning 10.19 10.17 10.18 10.40
Zero speed indicator bit 3.05 10.03
Feature Related parameters (Pr)
