EnC9
Drive encoder trip: Position feedback selected is selected from a Solutions Module slot which does not have a speed /
position feedback Solutions Module installed
197 Check setting of Pr 3.26 (Fb01, 0.71) (or Pr 21.21 if the second motor parameters have been enabled)
EnC10 Drive encoder trip: Termination overload
198 If the voltage from the encoder is >5V, then the termination resistors must be disabled (Pr 3.39 to 0)
Et External trip
6
Check terminal 31 signal
Check value of Pr 10.32
Enter 12001 in Pr xx.00 and check for parameter controlling Pr 10.32
Ensure Pr 10.32 or Pr 10.38 (=6) are not being controlled by serial comms
FbL No feedback from the tachgenerator or encoder
159
If the difference between the estimated speed (Pr 5.04) and the actual speed feedback (Pr 3.02 (di05, 0.40)) exceeds the value set
in the speed feedback loss window (Pr 3.56) the drive will trip Feedback loss. With fast acceleration rates in applications with low
load intertia estimated speed (Pr 5.04) may not track the actual speed feedback (Pr 3.02 (di05, 0.40)) fast enough and the speed
feedback loss window (Pr 3.56) may need to be increased.
Check the feedback device is connected correctly
Check motor name plate values have been entered into the drive correctly
Check the speed feedback in estimated speed mode - refer to running a motor section checking speed feedback
Carry out a rotating autotune
Fbr The polarity of the feedback tachgenerator or encoder is incorrect
160 Check that the feedback devices are connected correctly
FdL No current in the field supply circuit
168
Check that the field controller (Pr 5.77 (SE12, 0.33)) is enabled.
For the internal field controller check terminals L11, L12 are closed
Check internal auxiliary fuses, refer to section 4.9.3 Internal auxiliary fuses on page 42
FOC Excess current detected in field current feedback
169
Maximum current feedback is present
Check Field rated current (Pr 5.70 (SE10, 0.31)) and Field rated voltage (Pr 5.73 (SE11, 0.32)) are set correct to motor nameplate
Check for short circuit on field circuit cabling
Check integrity of motor insulation
F.OVL
Field I
2
t overload
157 See Pr 5.81 and Pr 5.82
HF01 Data processing error: CPU address error
Hardware fault - return drive to supplier
HF02 Data processing error: DMAC address error
Hardware fault - return drive to supplier
HF03 Data processing error: Illegal instruction
Hardware fault - return drive to supplier
HF04 Data processing error: Illegal slot instruction
Hardware fault - return drive to supplier
HF05 Data processing error: Undefined exception
Hardware fault - return drive to supplier
HF06 Data processing error: Reserved exception
Hardware fault - return drive to supplier
HF07 Data processing error: Watchdog failure
Hardware fault - return drive to supplier
HF08 Data processing error: Level 4 crash
Hardware fault - return drive to supplier
HF09 Data processing error: Heap overflow
Hardware fault - return drive to supplier
HF10 Data processing error: Router error
Hardware fault - return drive to supplier
Trip Diagnosis
To Next Page
