4.16 General
4.16.1 120V User I/O control terminal specifications
4.16.2 24 Vdc/Analog control terminal specification
C6 Digital input 1
C8 Digital input 2
C10 Digital input 3
C12 Digital input 4
C14 Digital input 5
C4 Digital input 6
Terminal C4 default function External trip input
Terminal C6 default function Not Stop
Terminal C8 default function Run
Terminal C10 default function Jog
Terminal C12 default function Forward/Reverse
Terminal C14 default function Reset
Type of input 120 Vac digital logic inputs
Maximum input voltage 132 Vac 50/60 Hz
Nominal input voltage range
96 Vac to 132 Vac
(120 Vac, +10% / -20%)
Nominal input frequency range
47 Hz to 53 Hz or 
56 Hz to 63 Hz
Voltage for ON state 79 Vac to 132 Vac
Current for ON state 2 mA to 3 mA
Voltage for OFF state 0 Vac to 20 Vac
Current for OFF state 0 mA to 1.5 mA
On fast update time 16.5 ms
Off fast update time 24.5 ms
C1 120 Vac user output
C3 120 Vac user output
C5 120 Vac user output
C7 120 Vac user output
C9 120 Vac user output
C11 120 Vac user output
C13 120 Vac user output
Terminal C1 Function
Supply for user external trip
(E-Stop) terminal C2
Terminal C3 Function
Supply for user external trip (Interlocks)
terminal C4
Terminal C5 Function
Supply for user Not Stop
terminal C6
Terminal C7 Function Supply for user Run terminal C8
Terminal C9 Function Supply for user Jog terminal C10
Terminal C11 Function
Supply for user Forward/Reverse
terminal C12
Terminal C13 Function
Supply for user Reset
terminal C14
Nominal output voltage 120 Vac
Maximum output current 250 mA total for all 120 Vac outputs
Protection Fuse
C15 120 Vac Relay output neutral
Terminal C15 Function
120 Vac Neutral connection point for
C16 relay output
C16 120 Vac relay output
Terminal C16 function Contactor enable (Drive ON)
Nominal output voltage 120 Vac
Update time ON 16.5 ms
Update time OFF 24.5 ms
Maximum output current 250 mA total for all 120 Vac outputs
Protection Fuse
1 0V common
Function
Common connection for all external
devices
2 +24V external input
Function
To supply the control circuit
without providing a supply to the
power stage
Nominal voltage +24.0 Vdc
Minimum continuous operating
voltage
+19.2 Vdc
Maximum continuous operating
voltage
+30.0 Vdc
Minimum start-up voltage 21.6 Vdc
Recommended power supply 60W 24 Vdc nominal
Recommended fuse 3A, 50 Vdc
3 0V common
Function
Common connection for all external
devices
4 +10V user output
Function Supply for external analog devices
Voltage tolerance 1%
Nominal output current 10 mA
Protection Current limit and trip @12 mA
