Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running
the Motor
Optimization
SMARTCARD
Operation
Onboard
PLC
Advanced
Parameters
Technical
Data
Diagnostics
UL
Information
72 Quantum MP User Guideï€
www.emersonct.com Issue: A4
7 Running the Motor
This chapter takes the new user through all the essential steps to
running a motor for the first time, in each of the possible operating
modes.
Table 7-1 Minimum control connection requirements for each
control mode
Refer to Figure 4-1 on page 28 for minimum connections to get a motor
running.
Verify 120 Vac control transformer is configured per Table 4-
6. Before applying line voltage to drive system! Otherwise,
damage to control transformer and/or 120 Vac I/O protection
fuse F3 could result.
Ensure that no damage or safety hazard could arise from the
motor starting unexpectedly.
The values of the motor parameters affect the protection of
the motor.
The default values in the drive should not be relied upon.
It is essential that the correct value is entered in Pr 5.07
(SE07, 0.28) Motor rated current. This affects the thermal
protection of the motor.
If the keypad mode has been used previously, ensure that
the keypad reference has been set to 0 using the
buttons as if the drive is started using the keypad it will run to
the speed defined by the keypad reference (Pr 1.17).
If the intended maximum speed affects the safety of the
machinery, additional independent over-speed protection
must be used.
Drive control method Requirements
Terminal mode
Drive enable
Speed reference
Run forward or run reverse
command
Keypad mode Drive enable
Serial communications
Drive enable
Serial communications link
