164 Quantum MP User Guide
www.emersonct.com Issue: A4
Table 13-2 Serial communications look-up table
13.3 Trip Categories
Trips can be grouped into the following categories. It should be noted that a trip can only occur when the drive is not tripped or is already tripped but
with a trip with a lower priority number.
Table 13-3 Trip categories
Unless otherwise stated, trips cannot be reset until 1.0s after the trip has been accepted by the drive
No. String No. String No. String
1
UU 90 UP div0 187 C.Typ
2 t002 91 UP Par 188 C.cpr
3 AOC 92 UP or 189 EnC1
4 t004 93 UP So 190 EnC2
5 PS 94 UP or 191 EnC3
6 Et 95 UP OFL 192-196 t192 - t196
7 O.SPd 96 UP uSEr 197 EnC9
8 PS.10V 97 UP AdV 198 EnC10
9 PS.24V 98 UP ACC 199 dESt
10 t010 99 t99 200 SL1.HF
11 tunE1 100 201 SL1.tO
12 tunE2 101 t101 202 SL1.Er
13 tunE3 102-111 t102 - t111 203 SL1.nF
14 tunE4 112-156 t112 - t156 204 SL1.dF
15 tunE5 157 F.OVL 205 SL2.HF
16 tunE6 158 AOP 206 SL2.tO
17 tunE7 159 Fable 207 SL2.Er
18 tunE 160 Fbr 208 SL2.nF
19 t019 161-167 t161 - t167 209 SL2.dF
20 It.AC 168 FdL 210 SL3.HF
21 O.ht1 169 FOC 211 SL3.tO
22 O.ht2 170 SL 212 SL3.Er
23 t023 171 S.OLd 213 SL3.nF
24 Th 172 S.Ov 214 SL3.dF
25 ThS 173 th.Err 215 SL.rtd
26 O.Ld1 174 PLL Err 216 t216
27 O.ht3 175 C.Prod 217-232 HF17 – HF32
28 cL2 176 t176
29 cL3 177 C.Boot
30 SCL 178 C.BUSy
31 EEF 179 C.Chg
32-33 t032 - t033 180 C.Optn
34 Pad 181 C.RdO
35 CL.bit 182 C.Err
36 SAVE.Er 183 C.dat
37 PSAVE.Er 184 C.FULL
38-39 t038 - t039 185 C.Acc
40-89 t040 - t089 186 C.rtg
Priority Category Trips Comments
1 Hardware faults HF01 to HF16
These indicate fatal problems and cannot be reset. The drive is
inactive after one of these trips and the display shows HFxx.
2 Non-resetable trips
HF17 to HF32, SL1.HF, SL2.HF,
SL3.HF
Cannot be reset
3 EEF trip EEF
Cannot be reset unless a code to load defaults is first entered in
parameter x.00
4 SMARTCARD trips
C.Boot, C.Busy, C.Chg, C.Optn,
C.RdO, C.Err, C.dat, C.FULL,
C.Acc, C.rtg, C.Typ, C.cpr,
SMARTCARD trips have priority 5 during power up.
4 Encoder power supply trips PS.24V, Enc1
These trips can only override the following priority 5 trips: Enc2 or
Enc9
5 Normal trips
All other trips not included in this
table
Can be reset after 1.0s
6 Self reseting trips UU
Under voltage trip cannot be reset by the user, but is automatically
reset by the drive when the supply voltage is with specification.
