152 Quantum MP User Guide
www.emersonct.com Issue: A4
Table 12-20 Bussmann semiconductor (line) fusing for 480V size 2 drives (Included in Quantum MP)
Four quadrant (R) drIves cannot use Bussmann FWH type fuses for line fusing. See ferraz shawmut Table 12-18 .
Table 12-21 Bussmann dc protection (armature) fusing for 480V size 2 drives (Included in Quantum MP).
Table 12-22 Ferraz Shawmut 120 Vac I/O protection fusing for 480V drives (Included in Quantum MP)
Table 12-23 Cooper Bussmann 120 Vac I/O protection fusing for 480V size 1 drives (Included in Quantum MP)
Table 12-24 Quantum MP drive SCR I
2
t rating for
semiconductor fusing
12.2.2 Torque settings
Table 12-25 Control terminal data
Table 12-26 Auxiliary and Field terminal data
Table 12-27 Drive power (L1, L2, L3, and GND) terminals
Table 12-28 Drive power (A1 and A2) terminals
Table 12-29 Dynamic Braking Resistor (DB+ and DB-) terminals
Model Fuse type
Rating
V
Rating
A
Catalog number
Control Techniques
number
Auxiliary 10x38mm ferrule 690V 25A FWC-25A10F 3533-2569
QMP350A4
North America style stud-mounting 500V
450A FWH-450A 3701-545000
QMP400A4 600A FWH-600A 3701-560000
QMP550A4 700A FWH-700A 3701-570000
QMP700A4 1000A FWH-1000A 3701-511001
Model Fuse type
Rating
V
Rating
A
Catalog number
Control Techniques
number
QMP350A4R
North America style stud-mounting 700V
450A FWP-450A 3701-745000
QMP400A4R 600A FWP-600A 3701-760000
QMP550A4R 700A FWP-700A 3701-770000
QMP700A4R 900A FWP-900A 3701-790000
Model Fuse type
Rating
V
Rating
A
Catalog number
Control Techniques
number
Size 1 10x38mm ferrule 600 Vac 0.5A ATQR1/2 212011-05
Size 2 10x38mm ferrule 600 Vac 1A ATQR1 3708-500100
Model Fuse type
Rating
V
Rating
A
Catalog number
Control Techniques
number
Size 1 10x38mm ferrule 600 Vac 0.5A FNQ-R-1/2 212011-05
Size 2 10x38mm ferrule 600 Vac 1A FNQ-R-1 3708-500100
Model
SCR I
2
t (A
2
s)
Auxiliary 400
QMP45A4(R) 3600
QMP75A4(R) 15000
QMP155A4(R)
80000
QMP210A4(R)
QMP350A4(R)
320000QMP4004(R)
QMP550A4(R)
QMP700A4(R) 1050000
Model Connection type Torque setting
All
Plug-in terminal block 0.5 Nm 0.4 lb ft
Model Connection type Torque setting
All
Terminal block 0.5 Nm 0.4 lb ft
Model Connection type Torque setting
QMP45A4(R)
2-14 AWG Slot Screw Lug 4-5.6 Nm 2.9-4.2 lb ft
QMP75A4(R)
2-14 AWG Slot Screw Lug 4-5.6 Nm 2.9-4.2 lb ft
QMP155A4(R)
5/16” Socket Lug 31 Nm 23 lb ft
QMP210A4(R)
5/16” Socket Lug 31 Nm 23 lb ft
QMP350-
700A4(R)
5/16” Socket Lug 31 Nm 23 lb ft
Model Connection type Torque setting
QMP45A4(R)
2-14 AWG Slot Screw Lug 4-5.6 Nm 2.9-4.2 lb ft
QMP75A4(R)
2-14 AWG Slot Screw Lug 4-5.6 Nm 2.9-4.2 lb ft
QMP155A4(R)
3/8” Socket Lug 42 Nm 31 lb ft
QMP210A4(R)
3/8” Socket Lug 42 Nm 31 lb ft
QMP350-
700A4(R)
5/16” Socket Lug 31 Nm 23 lb ft
Model Connection type Wire gauge
Torque setting
Nm lb ft
Size 1
Slotted lug
14-10 AWG 4 2.92
8 AWG 4.5 3.33
6-4 AWG 5 3.75
2 AWG 5.6 4.17
Size 2 31 23
