Probe length in in. (mm) Length L in in. (mm)
18 in. (457.2 mm) 24.5 (621)
3 ft. (0.9 m) 42.5 (1078)
6 ft. (1.8 m) 78.5 (1993)
9 ft. (2.7 m) 114.5 (2907)
Figure 1-7: Optional In-Situ Filters
A. In-situ stainless steel or Hastelloy filter
B. In-situ high surface area stainless steel filter
Figure 1-8: Optional Panel Mounted Blowback and Calibration/Reference Air
Set (19-in. [482.6 mm] Rack or Wall Mount)
Manual Description and specifications
00809-0500-4880 December 2022
Rosemount OCX8800A 21
