Figure 2-6: Terminal Block Top View
Earth ground typical for electronics and sensor housing.
A. Ground stud
2.3.8 Remote electronics connections to sensor housing
Make the following connections between the remote electronics and sensor
housings with the electronics cable ordered with the package (Figure 2-7). Braided
cable is available in lengths up to 150 ft (46 m).
