EMKO EAOM-19 - Top Label View of the Eaom-19

16
3.3TopLabelViewOfTheEAOM-19
12 13 14 15 16 17 18 19
MAINSN MAINSL1 MAINSL2 MAINSL3 GEN.N GEN.L1
MAINS
RELAY GEN.RELAY
5 A 5 A
1 2 3 4 5 6 7 8 9 10 11
BATTERY - BATTERY + BATTERY + START SOLENOID HORN
OIL
PRESS.
HIGH
TEMP.
CONF.
INPUT-1
CONF.
INPUT-2
CHARGE
GEN.
16 A 16 A 16 A
P/N:EAOM-19
-BAT
