20
Number Comment
11
Thebuttonisusedforchangingoperatingmodeoftheunittothe TEST Mode.
Theunitchangesoperatingmodetothe TEST ModeandLED(1)islitwhenthis
buttonispressed.
13
14
17
18
19
20
12
TheLAMP TEST functionoftheunitisoperatedandenteredintheProgramming
Modebyusingthisbutton. TheLAMP TEST functionoperateswhenthebuttonis
pressedfirst.Whenthebuttonispressedandkeepingpressedfor5secondsthe
unitispassedtothePROGRAMMINGModeandLED(2)islitatthesametime.
15
ThebuttonisusedfortransferringtheloadtothemainsonlyinMANUAL mode.
16
Thebuttonisusedfortransferringtheloadtothegenerator.Itisactiveonlyin
ManualMode.
21
Thebuttonisusedfordisconnectingtheloadfromthemains.Itisonlyactive
whentheunitisinMANUAL Mode.
22
Thebuttonisusedfordisconnectingtheloadfromthegenerator.Itisonlyactive
whentheunitisinMANUAL Mode.
23
AlternateDisplayModeButton.Itisusedforrotatingbetweenparametersand
approvingofthevalues,oftheunitanddisplays.Seesection4andSection6.1
24
MultiFunctionDisplay.ItisusedforProgrammingtheUnitandfeatures
explainedinsection6.
25
FailureIndicators.Detailedinformationaboutthissubjectisexplainedin
section6.2.
ThebuttonusedforstartingtheenginewhentheunitisintheMANUAL Mode.
TheLED(3)islitwhenthebuttonispressed.Itisonlyactivewhentheunitisin
MANUAL Mode.
ThebuttonisusedforchangingoperatingmodeoftheunittotheOFFMode. The
unitchangesoperatingmodetotheOFFModeandLED(6)islitwhenthisbutton
ispressed.
Thebuttonisusedforchangingoperatingmodeoftheunittothe AUTOMode.
Theunitchangesoperatingmodetothe AUTOModeandLED(7)islitwhenthis
buttonispressed.
ItrunsasHORNSILENCEandDECREMENT button. Thebutton,inthenormal
conditionsrunsforHORNSILENCEifthehornisrunningpurposewhenanyfailure
isdetected,itworksdecreasingvaluesofparametersinPROGRAMMINGMode.
ThebuttonisusedforstoppingtheenginewhentheunitisintheMANUAL
Mode. TheLED(8)islitwhenthe
buttonispressed.ItisonlyactivewhentheunitisinMANUAL Mode.
ItrunsasINCREMENT andFAILURERESET button. Thebutton,inthenormal
conditionsrunsforFAILURERESET purposewhenanyfailureisdetected,it
worksincreasingvaluesofparametersinPROGRAMMINGMode.
26
Generatorvoltageokayled.
27
Mainsvoltageokayled.
