6.1 AlternateDisplayDescription
6.Operation
33
Four-digit,seven-segmentLEDdisplay. Thismulti-functiondisplaytheselectedparameter
fromthelistalongside.UseDISPLAY MODE(23)buttontoselectwhichparameteristobe
displayed,asindicatedbytheadjacentLEDs. Thebuttonselectstheparametersin
sequence,asfollows.
Pleasenotethatphase-phasevoltagereadingsareprefixedby P'whilephase-neutral
readingsareprefixedby n'.
V MainsvoltageL1-L2,prefixL
GENV.-Generatorvoltage
GENFRG.-Generatorfrequency(Hz)
BATTERY -Batteryvoltage
The LEDwillflashiftheunitdetectsanenginestoppingerror.Whenthe
DISPLAY MODE(23)buttonispressedsoastoselectthisoption,thedisplaywillshow
thecauseoftheerrorindication. Thiserrormessageis:
StopError
The LEDwillbeskippedifthereisn’tanenginestoppingerror.
'
'
-
L12 -
V -MainsvoltageL1-N,prefix
V -MainsvoltageL2-L3,prefixL
V -MainsvoltageL2-N,prefix
V -MainsvoltageL3-L1,prefixL
V -MainsvoltageL3-N,prefix
HOUR-Engineworkingtime
L12
L23
L23
L31
L31
n
n
n
StP.E
ALARM
ALARM
VL12 GENV.
GENFRQ.
BATTERY
ALARM
VL23
VL31
