6- (ChargeGeneratorFailureLED): controlondelayAttheendof time
definedbyparameterP19,theunitchecks+VoltagewhichcomesfromCharge
GeneratorviaPin11.IfthereisnoVoltagetheunitdecidestoChargeGeneratorFailure.
InthiscasetheLEDflashesandtheHornissounded.
7- (BatteryVoltageFailureLED):
Batteryvoltagelowerlimit
8- (ConfigurableFailureInput-1LED):
9- (ConfigurableFailureInput-2LED):
BatteryVoltageFailureismonitored
continuesinallmodesexcept"OFF"mode. Thisfailureoccurscontinuouslywhenthe
batteryvoltagefallsbelowthevaluespecifiedbythe
parameterP11.InthiscasetheLEDflashesandtheHornissounded.Itisselfresetting
oncethefaulthasbeenremoved.
TheEAOM-19measuresbatteryvoltageattheEAOM-19terminals.Dependingonthe
sizeandlengthofthecabletothebattery,thismaybesomewhatlessthanthevoltageas
measuredatthebattery.
ConfigurableFailure-1inputworks
onvaluedeterminedinParameterP22.Whentheinputisactive(Pin9)theunitworks
accordingtoselectionofuser.
ConfigurableFailure-2inputworks
onvaluedeterminedinParameterP23.Whentheinputisactive(Pin10)theunitworks
accordingtoselectionofuser.
Bat.Voltage
Failure
SPARE1
SPARE2
OncetheEAOM-19hasgivenashutdownsignaltotheengineitexpectstheenginetorest.It
monitorsthe sourcesandiftheystillindicateenginemovementwhen
secondstimeperiodexpires, The alarmsignalisgenerated. The LED
willflashcontinually.
EngineStartedSignal
30 StPE
ALARM
StPE-StopErrorMessage(FailtoEngineStopping):
37
VL12 GENV.
GENFRQ.
BATTERY
ALARM
VL23
VL31
°F
