EMKO EAOM-19 - 8. Specifications

8.Specifications
40
EquipmentUse
Housing&Mounting
PanelCut-Out
Protection
Weight
EnviromentalRating
Operating/StorageTemperature
Operating/StorageHumidity
InstallationOverVoltage
Category
PollutionDegree
ModeOfOperation
DCBatteryVoltageSupply
CrankingDropouts
BatteryVoltageMeasurement
MainsVoltageMeasurement
GeneratorVoltage
Measurement
GeneratorSpeed(Frequency)
ChargeGeneratorExcitation
ContactSensingInputs
RelayOutputs
:Electricalcontrolequipmentforgeneratingsets
:72mmx72mmx95mm.(Includingconnectors)
¼DIN43700plastichousingforpanelmounting.
:69mmx69mm.
:NEMA 4X(Ip65atfrontpanel,Ip20atrearside).
: Approximately270gr.
:Standard,indooratanaltitudeoflessthen2000meters
withnon-condensinghumidity.
:-25Cto+70C/-40Cto+85C.
:90%max.(non-condensing)
:II Appliances,portableequipment
:II,Normalofficeorworkplace,nonconductivepollution.
:Continuous.
:8to32V ,max.operatingcurrentis240mA.
:Batteryvoltagecanbe"0"Voltformax.100msduring
cranking(batteryvoltageshouldbeatleastnominal
voltagebeforecranking).
:8to32V ,accuracy;1%FS,resolution;0,1V.
:Selectablethreephaseorsinglephase,4wire
connectionforthreephase,2wireconnectionforsingle
phasegen-set.35to300V Ph-N,15.6to99.9Hz.
Accuracy;1%FS,Resolution;1V.
:35to300V Ph-N,15.6to99.9Hz.
Accuracy;1%FS,Resolution;1V.
:15.6to99.9Hz.(min35V Ph-N)
Accuracy;0,25%FS,Resolution;0,1Hz.
:220mA,max4W.
:OilPressureSwitch(NC)
TemperatureSwitch(NO)
ConfigurableInput-1(NO)
ConfigurableInput-2(NO)
:Startrelay(1NO.16A@32V )
Fuelrelay(1NO.16A@32V )
Hornrelay(1NO.16A@32V )
Mainscontactorrelay(1NC.5A@250V )
Generatorcontactorrelay(1NO.5A@250V )
