EAOM-210 FLJ.eng / ver 0.0
Pages 132 / 132
Specification: Description:
OFF mode LED
TEST mode LED
AUTOMATIC mode LED
MANUAL mode LED
Engine start LED
Engine stop LED
Engine running
Main voltage available LED
Generator ready LED
Mains contactor LED
Status indicators
Generator contactor LED
Communication
interface
RS-232 serial port, ethernet module/dial-up modem or GSM
modem.
CanBus communication with Expansion module and J1939 ECU.
Emergency stop (NC)
Configurable failure input-1 (NO or NC selectable)
Configurable failure input-2 (NO or NC selectable)
Configurable failure input-3 (NO or NC selectable)
Low oil pressure or configurable failure input-4 (NO or NC
selectable)
High temperature or configurable failure input-5 (NO or NC
selectable)
Contact sensing inputs
Configurable failure input-6 (NO or NC selectable)
Fuel relay output. 16A at DC supply voltage
Start relay output. 16A at DC supply voltage
Horn or configurable relay output-1. 16A at DC supply voltage
Mains open relay output. 5A at DC supply voltage
Mains close relay output. 5A at DC supply voltage
Generator open relay output. 5A at DC supply voltage
Generator close relay output. 5A at DC supply voltage
Configurable relay output-2. 5A at DC supply voltage
Configurable relay output-3. 5A at DC supply voltage
Relay outputs
Configurable relay output-4. 5A at DC supply voltage
