0 - 7 4
DEVICE TYPE J1939 ECU Type Selection:
0- Disable
1- Standard
2- Volvo EMS2
3- Volvo EDC4
4- Perkins
(dis)0 - 4 DIS
DEVICE ADDRESS Device Address
0 - 255 17
ENGINE CONT.ADDRESS Engine Control Address
0 - 255 0
ECU REMOTE CONTROL ECU Remote Control via J1939
ENAB / DIS DIS
SENDING DM3 MESSAGE Reset Previously Active DTCs – DM3
No / Yes No
SPEED CONTROL ENAB Speed Control via J1939
ENAB / DIS DIS
OIL PRESS.CONT ENAB Oil Pressure Control via J1939
ENAB / DIS DIS
TEMPER.CONTROL ENAB Coolant Temperature Control via J1939
ENAB / DIS DIS
EXPANSION I/O MODULE SELECTION
If the Expansion I/O module is plugged the unit, this parameter must selected as “Enable”.
BAUD RATE
This parameter defines the used Baud rate. Note: all participants on the CAN bus must use
the same Baud rate.
DEVICE TYPE
The J1939 interface of this unit can be operated with different ECUs. This parameter
determines the operating mode of the used ECUs.
Note: if this parameter is selected as “disable”, No messages will be sent or received.
DEVICE ADDRESS
The unit sends J1939 request and control messages with this ID. It must be
changed for different ECU types according to the following table. The ECU
listens only to control messages, if they are sent to the correct address.
Volvo EMS2 Volvo EDC4 Perkins
17 3 43
Note: Changing above mentioned parameter becomes only effective after restarting the unit.
ENGINE CONTROL ADDRESS
This parameter configures the address of the J1939 ECU, which is controlled.
ECU REMOTE CONTROL via J1939
If this parameter is selected as “Enable”,
The unit sends remote start/stop messages to the
ECU if the selected ECU type is supporting the J1939 Remote control Messages. Available
messages are engine start or stop. For some ECUs;
Parameter
Volvo
EMS2
Volvo
EDC4
Perkins Standard
Remote Start
Yes No No No
Remote Stop
Yes No No No
