CG Drives & Automation 01-5958-01r0
Fig. 6 Example of a CTM 010 with 2 windings and a primary transformer
500:5 with 1 winding for a 260 A motor.
NOTE: The transformer connection and orientation are not polarity sensi-
tive, but must be connected to the same phase that is being referenced for
terminal 9 of the M20.
