4.1 Please note
1. Pay special attention to the safety section in this manual and parts marked
CAUTION.
2. Check that motor/supply voltage corresponds to values on the monitor
product label at the side of the unit.
3. Make a note of the motor’s rated power and full load amps from its
nameplate. Confirm that the current transformer supplied is of the correct
size according to tables 1 and 2 in chapter 6 of this manual.
4.2 Connection and set-up before first start
1. Connect the Emotron M20 according to chapter 5 and Fig. 1.
2. Make sure all safety measures have been taken and switch on the supply
voltage.
3. Use the key to scroll through the menu. Press and hold the key and
press the key to scroll back.
4. Set rated motor power and current in windows 41 and 42. Additional
settings to be programmed are discussed in chapter 8.
5. Set monitor function in window 05, overload and underload or only
underload or only overload. See chapter 12, Parameter list, for range and
default values.
6. Set start delay and response delay in window 31 and 32/34.
7. Compare all set values with the parameter list in chapter 12 to confirm that
all relevant values are set. Advanced features will be found in chapter 9.
