CG Drives & Automation 01-5958-01r0
• The Alarm window only appears if an Alarm output is active.
• The Actual Load window appears after power up.
• Use the key to scroll through the menu. Scroll back by pressing and
holding at the same time as the key is pressed.
• The Actual Load window (or alternative alarm window) will appear auto-
matically if no keys are pressed for longer than 1 minute.
• If the Parameter Lock is on, only windows (if alarm active)
are visible.
• Window selects the monitor function, see section 8.4.
7.3 How to change a value
Example: setting the rated motor current in window 42.
1. Press until the window number 42 appears.
2. Press or until the desired value is reached (e.g. 23 A), value flashes.
3. Press to confirm and save the change, value stops flashing.
NOTE: If the value is NOT to be changed, press the key.
CAUTION!
In order to avoid personal injury, make sure that all safety measures have
been taken before switching on the supply voltage and starting the motor/
machine.
