Emotron M20 - Page 51

CG Drives & Automation 01-5958-01r0
13
MIN Pre-Alarm (relay
R2)
0-125 0 %
0-745 0 kW
0-125 0 %
0-999 0
14
MIN Main Alarm
(relay R1)
0-125 0 %
0-745 0 kW
0-125 0 %
0-999 0
21
MAX Main Alarm
margin
0-100 16 %
22
MAX Pre-Alarm
margin
0-100 8 %
23
MIN Pre-Alarm
margin
0-100 8 %
24
MIN Main Alarm
margin
0-100 16 %
31 Start delay 1-999 2 s
32
Response delay over-
load
0.1-500 0.5 s
33 Hysteresis 0-50 0 %
34
Response delay
underload
0.1-500s 0.5 s
35* Pause/Reverse time 3-511 5 s
36*
Autoreset (start
attempts)
0-5 0
41 Rated motor power
0.10-745 2.2 kW
0.13-999 3
42 Rated current 0.01-999 5.6 A
43 Number of phases 1PH/3PH 3PH
61 Main alarm latch on/OFF OFF
Window Function Range Default Custom Symbol
