Appendix B, EMPower Connect Service Tool
© 2013 EMP, Inc 28
Reference Document(s)
and/or
Comments
Reference
Section
Input Requirement
Yes
No
Electrical
Is the positive power wire fused at 30 amps within 6
inches of the voltage source?
Electrical
Is the ignition (key switch power) fused from the source
or was an additional 5 amp fuse added to the ignition
wire within 6 inches of the ignition source? Identify
Specifications -
Electrical
Is the Ignition wire a minimum of 16 AWG?
Specifications -
Electrical
Is the power connected directly to the battery and the
wake/sleep of the pump controlled by the enable
signal? This is required for proper history and fault data
storage.
Specifications -
Electrical
If the pump is not CAN controlled, is the 6 pin connector
capped and contain all 6 cavity plugs?
Electrical
If the pump is CAN Controlled, is the CAN harness
potted and are provisions made to seal the shield wire?
Electrical
If the pump is CAN Controlled, is the pump PA #
properly specified for J1939 communication (J1939
address, CAN timeout, baud rate, etc)?
Electrical
Power and Plug installed and locked in position, no
stress on the wires at connectors?
Electrical
Are electrical cables shielded if within 6 inches of an
external heat source?
Electrical
Are electrical cables supported to prevent wear and
abrasion to the cables?
Orientation
Is the pump left to right angular orientation 5° to 15°
downward to allow proper weep hole drainage?
Orientation
Is the pump front to back angular orientation
10
to
allow proper weep hole drainage?
Orientation
Is there a feature on the pump mounting structure to
collect the small amount of weep that may escape the
pump?
Installation -
Plumbing
Are the inlet and outlet hoses aligned and supported to
reduce loading on the pump and bracket?
Plumbing
Are the hoses/tubes supported to reduce the risk of
rubbing?
Plumbing
Is the WP29 and WP32 inlet plumbing one inch internal
diameter from the coolant source?
Installation -
Plumbing
Are there 2-3 diameters of straight plumbing directly
before the inlet of the WP29 and WP32?
Plumbing
Is the WP29 and WP32 inlet plumbing “downhill” from
the coolant source?
