EMS AirFlow S1 - Replacement of the powder bowl set

30
AirFlow
®
S1
Replacement of the powder bowl set
Unscrew the cap for powder bowl (56) from outside of the
unit.
Remove the two screws (34) and the washers (26).
Dismantle the two uniclamps (92) and disconnect the yellow
air hose (66) and the transparent powder hose (85) from
the powder bowl set (35).
Put in place a new powder bowl set with the two O-rings
(33 and 37).
92
92 66
85
56
34 26 37 33
57
36
35
